Frequency response
USB DSD: 2Hz – 50kHz (-3dB)
USB PCM: 2Hz – 50kHz (-1.5dB)
CD: 2Hz – 20kHz
Total Harmonic Distortion
USB DSD: 0.0006%
USB PCM 24bit: 0.0005%
CD: 0.0015%
Signal to Noise Ratio
USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 118dB
Dynamic Range
USB DSD: 110dB
USB PCM 24bit: 118dB
CD: 101dB
Line Output Level
2.2Vrms
Headphone Output Level
28mW / 32 ohms
Power Consumption
38W
at Standby
0.3W
HDAM
New HDAM + HDAM-SA2
Power Transformer
EI
Headphone Amp
High slew rate op-amp
+ HDAM-SA2
H/P Amp Gain Setting
Yes (Low / Mid / High)
Digital Filter
Filter 1, 2 Selectable
CD Compatibility
CD / CD-R/RW / WMA / MP3 / AAC
Data Disc Compatibility
DSD / WAV / ALAC
Fixed Analog Output (RCA)
1 (Gold Plated)
Optical input / output (Maximum Support)
0 / 1
Coaxial input / output (Maximum Support)
0 / 1
Headphone Output
1
Remote Control Bus Terminal
Yes (RC-5 In / Out)
w/ External / Internal Select Switch
USB A
1 (Front)
Mass Storage Class
5V/1A
Support format
FAT 16/32
USB-A: FLAC / WAV / AIFF / ALAC / DSD
Yes
DSD Native Playback
Yes
USB Firmware Update
Yes
Unit (W x H x D mm)
442 x 129 x 396
Packaging Dimensions (W x H x D mm)
525×249×511
Net weight
7.5kg
Panel Color
Available Colors: Silver/Gold and Marantz Black
Front (Center) Panel
Aluminum
